| Managed Gigabit Switches
| D-LINK DGS-1510-52X 52-port Gigabit Layer 3 Smart Managed Switch with 4-port 10G Uplinks
D-LINK DGS-1510-52X 52-port Gigabit Layer 3 Smart Managed Switch with 4-port 10G Uplinks
เพิ่มเมื่อ: 2023-08-23 16:49:43.0
แก้ไขล่าสุด: 2023-11-06 16:22:38.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comDGS-1510-52X 52-port Gigabit Layer 3 Lite Stackable Smart Managed Switch with 4-port 10G Uplinks, 48 x 10/100/1000Base-T, 4 x 10G SFP+
D-LINK DGS-1510-52X
DGS-1510-52X 52-port Gigabit Layer 3 Lite Stackable Smart Managed Switch with 4-port 10G Uplinks
- 48 x 10/100/1000BASE-T ports
- 4 x 10G SFP+ ports
- Layer 2 management and security with Layer 3 capabilities
- Static Routing and MSTP
Specifications
- 1000Base-T Interface 48
- 10G SFP+ Interface 4
- Auto MDI/MDIX Yes
- Console Port Yes
- 10/100/1000BASE-T ports 48
- 10G SFP+ ports 4
- Switch Capacity 176 Gbps
- Max. Packet Forwarding Rate 130.95 Mpps
- Dimension 440mm x 210mm x 44mm
- Weight 3.1Kg
- Operation Temperature -5 -50°C
- Storage Temperature -20-70°C
- Operation Humidity 0% ~ 95% RH
- Storage Humidity 0% ~ 95% RH
- Maximum Power Consumption 48 W
- Standby Power Consumption 30.4Watt/100V 30.3Watt/240V
- Maximum Heat Dissipation 163.68 BTU/hr
- Acoustic 49.7 dB(A)
- MTBF 423,302 hours
- Power Input 100 - 240 VAC
- CPU Speed 400MHz
- DRAM Size 256MB
- Flash Memory Size 32MB
- Packet Buffer Size 3MB
- FAN 1 DC fan
- Comply with RoHS 6 Yes
- Energy Efficiency Ethernet (EEE) Yes
- Power Saving By System Hibernation Yes
- Power Saving By Link Status Yes
- Power Saving By LED Shut-Off Yes
- Power Saving By Port Shut-Off Yes
- Physical Stacking Yes
- Physical Stacking Bandwidth 40 G
- Units Per Physical Stack 6
- D-Link Single IP Management (SIM) Yes
- Units Per SIM Stack 32
- MAC Address Table Size 16384
- Black Hole MAC Address Yes
- 802.3x Flow Control Yes
- Head-of-line (HOL) Blocking Prevention Yes
- 802.1D Spanning Tree (STP) Yes
- 802.1w Rapid Spanning Tree (RSTP) Yes
- 802.1s Multiple Spanning Tree (MSTP) Yes
- Root Restriction Yes
- G.8032 ERPS Yes
- 802.1AX Link Aggregation Yes
- 802.3ad Link Aggregation Yes
- Link Aggregation Group Per Device 32
- Max Port Per Link Aggregation Group 8
- Port Mirroring Yes
- Flow-based (ACL) mirroring Yes
- Jumbo Frame 9216
- Loopback Detection (LBD) Yes
- IGMP Snooping Yes
- Max IGMP Snooping Groups 512
- IGMP Snooping Fast Leave Yes
- IGMP Proxy Reporting Yes
- MLD Snooping Yes
- MLD Snooping Groups Yes
- MLD Snooping Fast Leave Yes
- MLD Proxy Reporting Yes
- 802.1Q VLAN Yes
- VLAN Groups 4094
- Port-based VLAN Yes
- 802.1v Protocol-based VLAN Yes
- MAC-based VLAN Yes
- Voice VLAN Yes
- Auto Surveillance VLAN Yes, 2.1
- GVRP Yes
- Asymmetric VLAN Yes
- IP Interface Yes
- Max Number of IP Interface 16
- ARP Yes
- ARP Entries 512
- Gratuitous ARP Yes
- ND Entries Yes
- UDP Helper Yes
- Default Route Yes
- Static Route Yes
- Class of Service (CoS) Yes
- Number of Queue 8
- Remark 802.1p priority Yes
- Remark ToS/DSCP Yes
- Rate Limiting Yes
- Queue Handling Yes
- Strict Priority Queue (SPQ) Yes
- Weighted Round Robin (WRR) Yes
- Deficit Round Robin (DRR) Yes
- SPQ + WRR Yes
- Port-based Bandwidth Control Yes
- Max Access Control List (ACL) Entries Yes
- MAC Access List Yes
- IP Access List Yes
- IPv6 Access List Yes
- Time based ACL Yes
- SSH Yes
- SSL Yes
- Port Security Yes
- Broadcast/Multicast/Unicast Storm Control Yes
- Traffic Segmentation Yes
- IP Source Guard Yes
- DHCP Snooping Yes
- IPv6 Snooping Yes
- Dynamic ARP Inspection (DAI) Yes
- DHCPv6 Guard Yes
- IPv6 Route Advertisement (RA) Guard Yes
- IPv6 ND Inspection Yes
- Duplicate Address Detection (DAD) Yes
- D-Link Safeguard Engine Yes
- DHCP Server Screening Yes
- ARP Spoofing Prevention Yes
- BPDU Attack Protection Yes
- DoS Attack Prevention Yes
- 802.1X Yes
- Port based 802.1X Authentication Yes
- Host based 802.1X Authentication Yes
- Identity Driven 802.1X Policy Assignment Yes
- Web-based Access Control (WAC) Yes
- Port based WAC Authentication Yes
- Host based WAC Authentication Yes
- Identity Driven WAC Policy Assignment Yes
- Japanese Web-based Access Control (JWAC) Yes
- Port based JWAC Authentication Yes
- Host based JWAC Authentication Yes
- Identity Driven JWAC Policy Assignment Yes
- MAC-based Access Control (MAC) Yes
- Port based MAC Authentication Yes
- Host based MAC Authentication Yes
- Identity Driven MAC Policy Assignment Yes
- Compound Authentication Yes
- Guest VLAN Yes
Authentication for Management Access Yes
Privilege Level for Management Access 5
RADIUS Yes
RADIUS Accounting Yes
TACACS+ Yes
TACACS+ Accounting Yes
Cable Diagnostics Yes
Optical Transceiver Digital Diagnostic Monitoring (DDM) Yes
Network Time Protocol (NTP) Yes
Simple Network Time Protocol (SNTP) Yes
Web-based GUI Yes
Command Line Interface (CLI) Yes
Telnet Server Yes
Telnet Client Yes
SNMP Yes
SNMP Trap Yes
TFTP Client Yes
ZModem Yes
System Log Yes
RMONv1 Yes
LLDP Yes
LLDP-MED Yes
D-Link Discover Protocol (DDP) Yes (v0.25)
DHCP/BootP Client Yes
DHCP Auto-configuration Yes
DHCP relay Yes
Flash file system Yes
Multiple Images Yes
Multiple Configurations Yes
Editable Login Banner Yes
Editable System Prompt Yes
DNS Client Yes
Debug Command Yes
Password Encryption Yes
Ping Yes
Traceroute Yes
sFlow Yes
D-Link Network Assistant Yes
Smart Wizard Yes
SSH Yes
SSL Yes
Store-and-Forwarding Yes
