TP-LINK TL-SL2428 24-Port 10/100Mbps + 4 Gigabit RJ45 Ports and 2 Combo SFP Slots

 เพิ่มเมื่อ: 2017-03-08 15:23:14.0
 แก้ไขล่าสุด: 2019-05-06 17:14:39.0
 เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
 อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
TL-SL2428 24-Port 10/100Mbps + 4-Port Gigabit Smart Switch, 24 10/100Mbps RJ45 ports, 4 Gigabit RJ45 Ports and 2 Combo SFP Slots (สินค้ารับประกัน ตลอดอายุการใช้งาน)
5990.00 บาท

ส่งอีเมลล์ให้เพื่อน

TP-LINK TL-SL2428

TL-SL2428 24-Port 10/100Mbps + 4-Port Gigabit Smart Switch, 24 10/100Mbps RJ45 ports, 4 Gigabit RJ45 Ports and 2 Combo SFP Slots

- 24 10/100Mbps RJ45 Ports, 4 10/100/1000Mbps RJ45 Ports and 2 Combo Gigabit SFP Slots.

- Integrated security strategy including 802.1Q VLAN, Port Security and Storm control help protect LAN area -     investment.

- L2/L3/L4 QoS and IGMP snooping optimize voice and video application.

- WEB managed modes, SNMP, RMON bring abundant management features.



Hardware Features

- Standards and Protocols

        - IEEE 802.3i,IEEE 802.3u,IEEE 802.3ab,IEEE802.3z,IEEE 802.3x,IEEE 802.1d,IEEE 802.1s

          IEEE 802.1w,IEEE 802.1q,IEEE 802.1p

- Interface

        - 24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

        - 4 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

        - 2 Combo Gigabit SFP Slots

- Network Media

        - 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

        - 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)

         - 100BASE-FX:MMF,SMF

        - 1000BASE-X: MMF, SMF

        - Dimensions (W X D X H)

         - 17.3*7.1*1.7 in.(440*180*44 mm)

- Fan Quantity

        - Fanless

- Power Supply

         - 100~240VAC, 50/60Hz



Performance

- Bandwidth/Backplane 12.8Gbps

- MAC Address Table 8k

- Packet Forwarding Rate 9.5Mpps



Software Features

- Quality of Service

         - Support 802.1p CoS/DSCP priority

         - Support 4 priority queues

         - Queue scheduling: SP, WRR, SP+WRR

         - Port/Flow-based Rate Limiting

- L2 Features

         - IGMP Snooping V1/V2/V3

         - LAG(Up to 6 aggregation groups,

         - containing 4 ports per group)

         - Spanning Tree STP/RSTP/MSTP

         - BPDU Filtering/Guard

         - TC/Root Protect

         - Loop back detection

         - 802.3x Flow Control

- VLAN

         - Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)

- Security

         - Port Security

         - Broadcast/Multicast/Unknown-unicast Storm Control

Management

        - Web-based GUI

        - SNMP v1/v2c/v3,compatible with public MIBs and

        - TP-LINK private MIBs

         - RMON (1, 2, 3, 9 groups)

         - CPU Monitoring

         - Port Mirroring

         - Firmware Upgrade: Web

         - System Diagnose: VCT

         - SYSLOG & Public MIBS

Other

- Certification

- CE, FCC

Package Contents

- TP-LINK TL-SL2428; Switch

- Power Cord;

- Installation Guide;

- Resource CD;

- Rackmount Kit;

- Rubber Feet

System Requirements

- Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, GetWare, UNIX or Linux.
