D-LINK DGS-1510-52XMP 52-port Gigabit Layer 3 Smart Managed PoE (370W) Switch with 4-port 10G Uplink

 D-LINK DGS-1510-52XMP

DGS-1510-52XMP 52-port Gigabit Layer 3 Lite Stackable Smart Managed PoE (370W) Switch with 4-port 10G Uplinks

- 48 x 10/100/1000BASE-T PoE ports
- 4 x 10G SFP+ ports
- Layer 2 management and security with Layer 3 capabilities
- Static Routing and MSTP
- 370 W PoE budget (without RPS); 740 W PoE Budget (with RPS, only supports DPS-700)

Specifications

- 1000Base-T PoE Interface    48
- 10G SFP+ Interface    4
- Auto MDI/MDIX    Yes
- Console Port    Yes
- 10/100/1000BASE-T PoE ports    48
- 10G SFP+ ports    4
- Switch Capacity    176 Gbps
- Max. Packet Forwarding Rate    130.95 Mpps
- Dimension    440mm x 308.5mm x 44mm
- Weight    5.41 Kg
- Operation Temperature    -5 -50°C
- Storage Temperature    -20-70°C
- Operation Humidity    0% ~ 95% RH
- Storage Humidity    0% ~ 95% RH
- Maximum Power Consumption    486.9 W (PoE on)
58.8 W (PoE off)
- Standby Power Consumption    39.8W/100V, 40.1W/240V
- Maximum Heat Dissipation    1,660.33 BTU/hr
- Acoustic    55.4 dB(A)
- MTBF    303,027 hours
- Power Input    100 - 240 VAC
- CPU Speed    400MHz
- DRAM Size    256MB
- Flash Memory Size    32MB
- Packet Buffer Size    3MB
- FAN    4 DC Fans
- Comply with RoHS 6    Yes
- Energy Efficiency Ethernet (EEE)    Yes
- Power Saving By Link Status    Yes
- Power Saving By LED Shut-Off    Yes
- Power Saving By Port Shut-Off    Yes
- Time-based PoE    Yes
- Power Saving By System Hibernation    Yes
- PoE Budget    370 W (without RPS); Max. 740 W (with RPS, only supports DPS-700)
- Maximum PoE Budget    370W (w/o RPS); 740W (w/ RPS)
- PD Alive    Yes
- Physical Stacking    Yes
- Physical Stacking Bandwidth    40 G
- Units Per Physical Stack    6
- D-Link Single IP Management (SIM)    Yes
- Units Per SIM Stack    32
- MAC Address Table Size    16384
- Black Hole MAC Address    Yes
- 802.3x Flow Control    Yes
- Head-of-line (HOL) Blocking Prevention    Yes
- 802.1D Spanning Tree (STP)    Yes
- 802.1w Rapid Spanning Tree (RSTP)    Yes
- Root Restriction    Yes
- 802.1s Multiple Spanning Tree (MSTP)    Yes
- G.8032 ERPS    Yes
- 802.1AX Link Aggregation    Yes
- 802.3ad Link Aggregation    Yes
- Link Aggregation Group Per Device    32
- Max Port Per Link Aggregation Group    8
- Port Mirroring    Yes
- Flow-based (ACL) mirroring    Yes
- Jumbo Frame    9216
- Loopback Detection (LBD)    Yes
- IGMP Snooping    Yes
- Max IGMP Snooping Groups    512
- IGMP Snooping Fast Leave    Yes
- IGMP Proxy Reporting    Yes
- MLD Snooping    Yes
- MLD Snooping Fast Leave    Yes
- MLD Proxy Reporting    Yes
- MLD Snooping Groups    Yes
- 802.1Q VLAN    Yes
- VLAN Groups    4094
- Port-based VLAN    Yes
- 802.1v Protocol-based VLAN    Yes
- MAC-based VLAN    Yes
- Voice VLAN    Yes
- Auto Surveillance VLAN    Yes, 2.1
- GVRP    Yes
- Asymmetric VLAN    Yes
- IP Interface    Yes
- Max Number of IP Interface    16
- ARP    Yes
- ARP Entries    512
- Gratuitous ARP    Yes
- ND Entries    Yes
- UDP Helper    Yes
- Default Route    Yes
- Static Route    Yes
- Number of Queue    8
- Class of Service (CoS)    Yes
- Remark 802.1p priority    Yes
- Remark ToS/DSCP    Yes
- Rate Limiting    Yes
- Queue Handling    Yes
- Strict Priority Queue (SPQ)    Yes
- Weighted Round Robin (WRR)    Yes
- Deficit Round Robin (DRR)    Yes
- SPQ + WRR    Yes
- Port-based Bandwidth Control    Yes
- Max Access Control List (ACL) Entries    Yes
- MAC Access List    Yes
- IP Access List    Yes
- IPv6 Access List    Yes
- Time based ACL    Yes
- SSL    Yes
- SSH    Yes
- Broadcast/Multicast/Unicast Storm Control    Yes
- Traffic Segmentation    Yes
- Port Security    Yes
- DHCP Snooping    Yes
- IPv6 Snooping    Yes
- Dynamic ARP Inspection (DAI)    Yes
- IP Source Guard    Yes
- DHCPv6 Guard    Yes
- IPv6 Route Advertisement (RA) Guard    Yes
- Duplicate Address Detection (DAD)    Yes
- IPv6 ND Inspection    Yes
- D-Link Safeguard Engine    Yes
- ARP Spoofing Prevention    Yes
- DHCP Server Screening    Yes
- BPDU Attack Protection    Yes
- DoS Attack Prevention    Yes
- 802.1X    Yes
- Port based 802.1X Authentication    Yes
- Host based 802.1X Authentication    Yes
- Identity Driven 802.1X Policy Assignment    Yes
- Web-based Access Control (WAC)    Yes
- Port based WAC Authentication    Yes
- Host based WAC Authentication    Yes
- Japanese Web-based Access Control (JWAC)    Yes
- Identity Driven WAC Policy Assignment    Yes
- Host based JWAC Authentication    Yes
- Port based JWAC Authentication    Yes
- Port based MAC Authentication    Yes
- MAC-based Access Control (MAC)    Yes
- Identity Driven JWAC Policy Assignment    Yes
- Identity Driven MAC Policy Assignment    Yes
- Compound Authentication    Yes
- Guest VLAN    Yes
- Host based MAC Authentication    Yes
- Authentication for Management Access    Yes
- Privilege Level for Management Access    5
- RADIUS    Yes
- RADIUS Accounting    Yes
- TACACS+    Yes
- TACACS+ Accounting    Yes
- Cable Diagnostics    Yes
- Optical Transceiver Digital Diagnostic Monitoring (DDM)    Yes
- Network Time Protocol (NTP)    Yes
- Simple Network Time Protocol (SNTP)    Yes
- Command Line Interface (CLI)    Yes
- Web-based GUI    Yes
- SNMP    Yes
- Telnet Client    Yes
- Telnet Server    Yes
- ZModem    Yes
- System Log    Yes
- TFTP Client    Yes
- SNMP Trap    Yes
- RMONv1    Yes
- LLDP    Yes
- LLDP-MED    Yes
- DHCP/BootP Client    Yes
- D-Link Discover Protocol (DDP)    Yes (v0.25)
- DHCP relay    Yes
- DHCP Auto-configuration    Yes
- Flash file system    Yes
- Editable Login Banner    Yes
- Multiple Configurations    Yes
- Multiple Images    Yes
- Editable System Prompt    Yes
- DNS Client    Yes
- Debug Command    Yes
- Traceroute    Yes
- Password Encryption    Yes
- Ping    Yes
- D-Link Network Assistant    Yes
- sFlow    Yes
- Smart Wizard    Yes
- SSH    Yes
- SSL    Yes
- Store-and-Forwarding    Yes
