D-LINK DEM-432XT 10GBASE-LR (Duplex LC) Single-mode SFP+ Transceiver, 10km
เพิ่มเมื่อ: 2019-09-25 13:26:34.0
แก้ไขล่าสุด: 2023-11-15 12:09:49.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comDEM-432XT 10GBASE-LR (Duplex LC) Single-mode SFP+ Transceiver, 10km (w/o DDM)10GBase-LR SFP+ Transceiver (Singlemode 1310nm) - 10km
D-LINK DEM-432XT
DEM-432XT 10GBASE-LR (Duplex LC) Single-mode SFP+ Transceiver, 10km
(w/o DDM)10GBase-LR SFP+ Transceiver (Singlemode 1310nm) - 10km
Standard Compliance
- IEEE-802.3ae, 10GBASE-SR
Form Factor Type
- SFP+
Fibre Channel FC-PI Standard
- 1200-SM-LL-L
Fiber Media Support
- Single-Mode
Distance Capacity
- 10 km
Features
- Hot Pluggable
- MSA Compliant
- RoHS Compliant
Speed
- 10 Gbps
Connector
- Duplex LC Connector
Single/Bi-Directional
- Single Direction
WavelengthTX
- 1330nm, RX: 1310 nm
Output Optical Power (TX Optical Power)
- Max.: 0.5 dBm
- Min.: -8.5 dBm
Input Optical Power (RX Optical Power)
- Max.: 0.5 dBm
- Min.: -8.5 dBm
Sensitivity
-12.6 dBm
Cable Type
- Single-mode 9/125 um fiber
Power
- 3.3V
Maximum Input Current
- 3.3V: 300mA
Minimum Power Budget
- 4.1 dB
Maximum Power Budget
- 10.1 dB
Heat Generated
- 3.6 kJ/h
MTBF (hours)
- 4,650,000
Operating temperature
- 0 to 70°C
Storage temperature
- -40 to 85 °C
Operating humidity
- 5 to 85%
Storage humidity
- 5 to 95%
Dimensions
- Compliant with SFF8432
- 14.8 x 56.5 x 11.85mm
Weight
- 19.5 g
Bail Latch Color
- Blue
EMI
- CE, FCC, VCCI
Safety
- UL, TUV, CDRH
