PLANET VC-202A 1-Port 10/100Base-TX + 1-Port BNC Ethernet over Coaxial Extender

 เพิ่มเมื่อ: 16/10/2013
 แก้ไขล่าสุด: 13/05/2019
 เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
 อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
VC-202A 1-Port 10/100Base-TX + 1-Port BNC Ethernet over Coaxial Extender (สินค้ารับประกัน 3 ปี)
4,200.00 บาท

PLANET VC-202A

VC-202A 1-Port 10/100Base-TX + 1-Port BNC Ethernet over Coaxial Extender

Defines Asymmetric (Plan 998) and Symmetric for the transmission of upstream and downstream signals

Cost-effective Profile 17a CO / CPE bridge solution

One box design, CO / CPE selectable via DIP Switch

Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards

DMT (Discrete Multi-Tone) line coding

Half Duplex Back-Pressure and IEEE 802.3x Full Duplex Pause Frame Flow-Control

Supports up to 1,536 bytes packet size, IEEE 802.1Q VLAN tag transparent

Standalone transceiver for simple bridge modem application

Advantage of minimum installation time (Simply as Plug-and-Play)

Selectable target band plan and target SNR margin

Supports extensive LED indicators for network diagnostics

Co-work with PLANET MC family Media Chassis (MC-700 / 1500 / 1500R / 1500R48)

Compact in size, easy installation



Community / Campus Surveillance and Security over IP
To take advantage of digital surveillance system and keep the benefits of coaxial cable, the VC-202A helps the community, campus and enterprises to upgrade analog camera system to IP camera surveillance without using additional new wires. The Extender is a switching architecture with one RJ-45 10/100Mbps Fast Ethernet port and one BNC Ethernet over Coaxial port. Just plug-in the UTP cable of IP camera to Ethernet port and the existing coaxial cable to the BNC connector. It is easy to deploy and extend the distance with signal conversion by transmitting the Ethernet data from the standard coaxial cable. Furthermore, with high transmit data rate, the VC-202A solution supports multiple IP cameras input for sharing in one coaxial cable to reduce the cost of cabling.

MTU / MDU / Hospitality Solution
IPTV, VOD and digital message broadcasting services are the worldwide hot trends, and more and more service providers have upgraded the client side devices from analog system to digital system gradually. The VC-202A will be the best solution because it provides cost-effective and high speed network services by utilizing the existing coaxial cable infrastructure. IP network installation is straightforward. With enough bandwidth, the 100/100Mbps symmetric capability of VC-202A makes many Multi-Media services on local Internet come true, such as VOD (Video on Demand), Voice over IP, Video phone, IPTV, distance education, and so on. It satisfies most of entertainment and communication layer. Meanwhile, this kind of infrastructure also minimizes the burden on the Internet.



Commercial Location Media Network and Electronic Billboards
More and more media network and electronic billboards are built in commercial locations to deliver information over office buildings, shopping centers and stations in the cities. Integrating with Set-Top Box and LCD TV, the VC-202A provides an immediate and interactive broadcasting system over direct Ethernet connection instead of constant content and data exchange by human resource. It can also be integrated with IPTV and Web TV. Through the remote management function, administrators can interrupt the TV program for the News and the commercials. It saves labor and gets better commercial effect.



Hardware Specification
Ports • 10/100Base-TX: 1 RJ-45, Auto-negotiation and Auto-MDI / MDI-X
• Coaxial: 1 BNC, female connector
DIP Switch 4 position DIP switch
Functionality • CO / CPE mode select
• Selectable fast and interleaved mode
• Selectable target Band Plan
• Selectable target SNR mode
Encoding •DMT (Discrete Multi-Tone) line coding
- ITU-T G.997.1
- ITU-T G.993.1
- ITU-T G.993.2 (Profile 17a Support)
LED Indicators • One Power
• 3 for Coaxial (BNC):
- Green, LNK
- Green, CO mode
- Green, CPE mode
• 2 for per RJ-45 10/100Base-TX port
- Green, LNK / ACT
- Green, Speed
Cabling • Ethernet : 10Base-T: 2-pair UTP Cat.3, 4 and 5 up to 100m (328ft)
• Ethernet : 100Base-TX: 2-pair UTP Cat.5, 5e and 6 up to 100m (328ft)
• Coaxial Cable: 50ohm, RG58A / U, RG58C / U, RG58 / U or equivalent; 75ohm, RG-6 (Distance up to 3.0km)
Performance Asymmetric:
200m ->100/65Mbps
400m ->100/64Mbps
600m ->100/59Mbps
800m ->100/53Mbps
1000m -> 94/44Mbps
1200m -> 84/36Mbps
1400m -> 74/28Mbps
1600m -> 66/19Mbps
1800m -> 60/14Mbps
2000m -> 44/15Mbps
2200m -> 35/12Mbps
2400m -> 32/10Mbps
2600m -> 29/8Mbps
2800m -> 27/6Mbps
3000m -> 25/5Mbps

Symmetric:
200m ->99.7/100Mbps
400m ->100/100Mbps
600m -> 86/91Mbps
800m -> 79/80Mbps
1000m -> 69/66Mbps
1200m -> 60/52Mbps
1400m -> 51/41Mbps
1600m -> 45/36Mbps
1800m -> 40/29Mbps
2000m -> 27/26Mbps
2200m -> 23/24Mbps
2400m -> 22/21Mbps
2600m -> 20/18Mbps
2800m -> 18/15Mbps
3000m -> 17/13Mbps
Dimension (W x D x H) 97 x 70 x 26 mm
Weight 0.2 kg
Power Requirement 5V DC 2A
Power Consumption 6.3Watts / 21BTU (maximum)
Standard Conformance
Regulation Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Full Duplex Pause Frame Flow-Control
ITU-T
- G.993.1
- G.997.1
- G.993.2 (Profile 17a Support)
Environment
Operating Temperature: 0 ~ 50 Degree C
Humidity:5~90%, relative humidity (non-condensing)
Storage Temperature: -10~70 Degree C
Humidity:5~90%, relative humidity (non-condensing)
