Mikrotik CCR2004-1G-12S+2XS Cloud Core Router 2004-1G-12S+2XS with Annapurna Alpine AL32400 Cortex A
เพิ่มเมื่อ: 2023-11-17 17:49:29.0
แก้ไขล่าสุด: 2023-11-24 14:01:06.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comไมโครติค CCR2004-1G-12S+2XS Cloud Core Router 2004-1G-12S+2XS with Annapurna Alpine AL32400 Cortex A57 CPU (4-cores, 1.7GHz per core), 4GB RAM, 1x Gigabit RJ45 port, 12x 10G SFP+ cages, 2 x 25G SFP28 cages, RouterOS L6, 1U rackmount case (1 Years)
Mikrotik CCR2004-1G-12S+2XS
CCR2004-1G-12S+2XS Cloud Core Router 2004-1G-12S+2XS with Annapurna Alpine AL32400 Cortex A57 CPU (4-cores, 1.7GHz per core), 4GB RAM, 1x Gigabit RJ45 port, 12x 10G SFP+ cages, 2 x 25G SFP28 cages, RouterOS L6, 1U rackmount case, Dual PSU
Specifications
Details
- Product code CCR2004-1G-12S+2XS
- Architecture ARM 64bit
- CPU AL32400
- CPU core count 4
- CPU nominal frequency 1700 MHz
- Dimensions 443 x 224 x 44 mm
- RouterOS license 6
- Operating System RouterOS v7
- Size of RAM 4 GB
- Storage size 128 MB
- Storage type NAND
- MTBF Approximately 200'000 hours at 25C
- Tested ambient temperature -20°C to 60°C
- IPsec hardware acceleration Yes
Powering
- Details
- Number of AC inputs 2
- AC input range 100-240
- Max power consumption 49 W
- Max power consumption without attachments 32 W
- Cooling type 2 fans
Ethernet
- Details
- 10/100/1000 Ethernet ports 1
Fiber
- Details
- SFP+ ports 12
- Number of 25G SFP28 ports 2
Peripherals
- Details
- Serial console port RJ45
Other
- Details
- CPU temperature monitor Yes
- PCB temperature monitor Yes
- Voltage Monitor Yes
Certification & Approvals
- Details
- Certification CE, EAC, ROHS
- IP 20
