PLANET VC-203PT PoE over Coaxial Extender – Transmitter
เพิ่มเมื่อ: 2017-06-19 14:20:08.0
แก้ไขล่าสุด: 2019-05-13 13:13:36.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comVC-203PT PoE over Coaxial Extender – Transmitter (สินค้ารับประกัน 3 ปี)
PLANET VC-203PR
VC-203PR PoE over Coaxial Extender – Receiver
PLANET VC-203Px series of PoE over Coaxial Extender is designed to extend IP Ethernet transmission and inject power over an existing coaxial cable for distance up to 1000m (3280ft) to PoE IP camera, PoE Wireless AP and any 802.3af/at complied powered device (PD).
The VC-203Px consists of a Transmitter and Receiver set which can work in pair without any power adapter and anywhere on your network infrastructure. The solution contains two brand-new products:
VC-203PT: 1-Port 10/100TX PoE PD + 1-Port BNC PoE over Coaxial PSE Extender – Transmitter
VC-203PR: 1-Port 10/100TX PoE PSE + 1-Port BNC PoE over Coaxial PD Extender – Receiver
|
Models
|
VC-203PT
|
VC-203PR
|
|
|
Power over Coax. Extender
|
Transmitter
|
Receiver
|
|
|
Power Input
(Optional) |
PoE
|
RJ-45: 802.3af/at PoE In
UTP cable, up to 100m |
BNC: PoE over Coaxial In
Coaxial cable, up to 1km |
|
DC
|
DC Jack: 52~56V DC In
|
DC Jack: 52~56V DC In
|
|
|
Power Output
|
PoE
|
BNC: Power over Coaxial Out
Coaxial cable, up to 1km |
RJ-45: 802.3af/at PoE out
UTP cable, up to 100m |
|
DC
|
--
|
2-Pin Terminal Block :
Selectable 12V/24V DC |
|
Features
Physical Port
- 1 x 10/100Base-TX RJ-45 copper interface (PoE IN)
- 1 x BNC connector (Power and data transmitter)
Power over Ethernet
- Eliminates Power cabling with PoE over Coaxial
- Ethernet over coaxial up to 1km with 5C2V/RG6 75Ωcable
- Complies with IEEE 802.3af / IEEE 802.3at Power over Ethernet on RJ-45 port
- Supports PoE Power up to 30.8 watts (Varying with Power Source and Coaxial Distance)
Layer 2 Features
- Supports auto-negotiation and 10/100Mbps half / full duplex
- Prevents packet loss with back pressure (half duplex) and IEEE 802.3x pause frame flow control (full duplex)
VDSL2 Features
- One box design, Master / Slave selectable via DIP Switch
- Defines asymmetric (Band Plan 998) and symmetric band plans for the transmission of upstream and downstream signals
Industrial Case / Installation
- Supports extensive LED indicators for network diagnostics
- IP30 metal case protection
- Flexible power source either extemal DC or PoE power input
- Supports EFT protection 2000 VDC for power line
- Supports 2000 VDC Ethernet ESD protection
- -40 to 75 degrees C operating temperature
