TP-LINK FC311B-2 Omada Gigabit WDM Media Converter
เพิ่มเมื่อ: 2025-01-15 11:41:51.0
แก้ไขล่าสุด: 2025-01-15 11:42:01.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comMedia Converter TP-LINK FC311B-2 10/100/1000 Mbps RJ45 to 1000 Mbps Single-mode SC WDM Bi-Directional Fiber Converter, Full-duplex, Tx:1310 nm, Rx:1550 nm, Up to 2 km (รับประกัน 1 ปี)
TP-LINK FC311B-2
Media Converter TP-LINK FC311B-2 10/100/1000 Mbps RJ45 to 1000 Mbps Single-mode SC WDM Bi-Directional Fiber Converter, Full-duplex, Tx:1310 nm, Rx:1550 nm, Up to 2 km
- 1× 10/100/1000Mbps Auto-Negotiation RJ45 port supports Auto-MDI/MDIX
- Auto-negotiation of Half-Duplex/Full-Duplex transfer mode
- Adopts WDM technology, transmitting and receiving data on one single fiber
- Extends fiber distance up to 2 km
Standards and Protocols :
IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z
Interface :
• 1× Gigabit SC/UPC Fiber Port
• 1× 10/100/1000 Mbps RJ45 Port (Auto MDI/MDIX)
Network Media :
• Single-mode Fiber (9/125μm, maximum 2km)
• UTP category 5, 5e cable (maximum 100m)
Power Supply : External Power Adapter: 5 V/0.6 A
LED : PWR, Link/Act
Wave Length : 1550 nm TX, 1310 nm RX
Dimensions ( W x D x H ) : 3.7×2.9×1.1 in (94.5×73.0×27.0 mm)
Package Contents :
• Media Converter FC311A-2
• Power Adapter
• Installation Guide
