IP-COM G3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch
เพิ่มเมื่อ: 2024-01-05 18:23:47.0
แก้ไขล่าสุด: 2024-08-06 18:02:10.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comG3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch(สินค้ารับประกัน 3ปี)
IP-COM G3310P-8-150W
G3310P-8-150W 8GE+2SFP Cloud Managed PoE Switch
- Compliance with IEEE 802.3/3u/3ab/3x/3z/1p/q/w/d/3af/at standards
- 8 x 10/100/1000 Base-T Ethernet ports (Data/Power) 2 x 100/1000 Base-X SFP ports
- 8K MAC address and MAC address automatic learning
- IEEE 802.3x full-duplex flow control and half-duplex backpressure flow control
- Non-blocking line-rate forwarding for all ports
- Maximum output power of a single PoE port: 30W
- Maximum output power of the whole switch: 130W
- IEEE 802.1Q VLAN Link aggregation QoS MAC address binding
- Supports App management and visualized local management
Specification
Hardware specifications
Standards :
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.1p, IEEE 802.1q, IEEE 802.1w, IEEE 802.1d, IEEE 802.3af, IEEE 802.3at
LED indicators :
1 Link/Ack LED indicator for each port
1 PoE Max LED indicator for each device
1 Power LED indicator for each device
1 SYS LED indicator for each device
Interfaces :
8 x 10/100/1000 Base-T Ethernet ports (Data/Power)
2 x 100/1000 Base-X SFP ports
Port Lightning Protection : ≥6KV
Forwarding mode : Store-and-forward
Switching capability : 20 Gbps
Packet forwarding rate : 14.9 Mpps
MAC address table : 8K
PoE Power Supply :
Ports 1 to 8 support 802.3af/at standard
1 2 4 5 +, 3 6 7 8 -
Input voltage : 100-240V～ 50/60Hz
Dimensions(L*W*H) : 294 mm * 179.6 mm * 44 mm
Whole Switch Power Consumption :
Whole switch power consumption: <150W;
Maximum PoE output power: 130W
Operating environment :
Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage humidity: (5% - 90%)RH, non-condensing
Software specifications
PoE Power Supply Management Port PoE configuration and power supply priority configuration supported
PoE over-temperature protection supported
Smart graphical management and PoE-powered device detection supported
(port status, power assignment, and PoE-powered device status)
Security Features MAC address binding supported
VLAN IEEE 802.1Q VLAN supported
Port aggregation Static aggregation supported
Dynamic aggregation supported
Spanning tree IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) supported
Port Mirroring N: 1 port mirroring supported
QoS FIFO (First-In, First-Out) supported
SP (Strict Priority) supported
WP (Weighted Priority) supported
Loading & Upgrade HTTP upgrade supported
Configuration import and export supported
Cloud management Supports configuration delivery from IMS cloud platform
Supports log reporting and fault detection
Supports remote maintenance: reboot, backup, upgrade
Local visualization management Supports router, switch, AP, IP camera discovery
Supports automatic generation of topology
Supports online/offline status detection for devices
Supports remotely rebooting the IP camera
