COMMSCOPE CBC-0007
CAT 6 UTP CABLE 23 AWG, CMR Blue 305 M./Box (884023394/10)
ANSI/TIA Category : 6
Cable Component Type : Horizontal
Cable Type : U/UTP (unshielded)
Conductor Type, singles : Solid
Conductors, quantity : 8
Jacket Color : Blue
Note : All electrical transmission tests include swept frequency measurements
Pairs, quantity : 4
Separator Type : Isolator
Supported Application : 1000BASE-T | 1000BASE-TX | 100BASE-TX | 10BASE-T | 155Mbps ATM | TP-PMD | Token Ring | VoIP
Transmission Standards : ANSI/TIA-568.2-D | CENELEC EN 50288-6-1 | IEC 61156-5 | ISO/IEC 11801 Class E
Cable Length : 304.8 m | 1000 ft
Diameter Over Insulated Conductor : 0.980 mm | 0.0386 in
Diameter Over Jacket, nominal : 5.751 mm | 0.2264 in
Conductor Gauge, singles : 23 AWG
Characteristic Impedance : 100 ohm
dc Resistance Unbalance, maximum : 5 %
dc Resistance, maximum : 8 ohms/100 m | 2.438 ohms/100 ft
Delay Skew, maximum : 45 ns
Dielectric Strength, minimum : 1500 Vac | 2500 Vdc
Mutual Capacitance at Frequency : 5.6 nF/100 m @ 1 kHz
Nominal Velocity of Propagation (NVP) : 68 %
Operating Frequency, maximum : 250 MHz
Operating Voltage, maximum : 80 V
Propagation Delay, maximum : 536 ns/100m @250MHz
Remote Powering : Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A
|
|
|
|
