TENDA N6P-4H 4 Channel PoE HD Network Video Recorder
เพิ่มเมื่อ: 2022-12-23 16:00:51.0
แก้ไขล่าสุด: 2025-01-31 12:48:26.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comN6P-4H 4 Channel PoE HD Network Video Recorder
TENDA N6P-4H
N6P-4H PoE HD Network Video Recorder supports PoE power supply, plug and play, 4K UHD recording and output, channel cloud storage, H.265 high-performance video compression and monitor video viewing on TDSEE App. It is suitable for such scenarios as single-family houses, shops, restaurants, offices, factories and farms, providing you efficient and convenient monitoring management.
Video
- IP Video Input 4-ch
- IP Video Resolution Up to 8MP
- Input Bandwidth 60 Mbps
- Audio Input 1-ch, RCA (2.0 Vp-p, 10kΩ)
Video&Audio Output
- HDMI Output 1-ch, 4K(3840×2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
- Output Bandwidth 60 Mbps
- Audio Output 1-ch, RCA (2.0 Vp-p, 10kΩ)
Video&Audio Output
- HDMI Output 1-ch, 4K(3840×2160)/30Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
- VGA Output 1-ch, 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
- Output Bandwidth 60 Mbps
- Audio Output 1-ch, RCA (2.0 Vp-p, 10kΩ)
Video&Audio Decoding
- Video Decoding Format H.265+, H.265, H.264+, H.264
- Audio Decoding Format G.711A, G.711U, G726
- Recording Resolution 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
- Decoding Capability 4-ch@1080p(30 fps)
- Stream Type Video, Video & Audio
Recording Management
- Record Mode Normal, Alarm
- Playback Moden Instant, Channel, File, Tag
- Sync Playback Up to 4-ch
- Backup Mode USB device
Network Managemant
- Ethernet Port 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port
- Network Protocol HTTP, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, DDNS
- Mobile Client Supports iOS, Android
- Web Browser Plug-in free live view : Chrome, Edge, Opera
PoE
- PoE Port 4 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet ports
- PoE Standard IEEE 802.3at/802.3af
- PoE Power ≤40 W
HDD Storage
- HDD Interface 1 SATA 3.0 interface
- Capacity Up to 10 TB capacity for each HDD
External Interface
-USB Port 2 x USB 2.0
General
- Power 51 VDC, 1.25 A
- Dimension 200 mm × 200 mm × 48 mm (7.9 ”× 7.9 ” × 1.9 ”)
- Weight (Without HDD) 510g (1.12lb)
- Certification CCC, CE, FCC, RoHS
- Installation Method Desktop mounting, wall mounting
- Temperature Operating Temperature: 0°C - 40°C (32°F - 104°F)
Storage Temperature: -30°C - 70°C (-22°F - 158°F)
- Humidity Operating Humidity: 10% - 90% RH (non-condensing)
Storage Humidity: 5% - 95% RH (non-condensing)
