AIRPHO AR-GS216 16-port Gigabit Rackmount Switch
เพิ่มเมื่อ: 2019-10-09 14:48:39.0
แก้ไขล่าสุด: 2023-11-16 11:44:35.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comAR-GS216 16-port Gigabit Rackmount Switch 16 10/100/1000Mbps RJ45 ports 19-inch rack mount (สินค้ารับประกันตลอดอายุการใช้งาน)
AIRPHO AR-GS216
AR-GS216 16-port Gigabit Rackmount Switch 16 10/100/1000Mbps RJ45 ports
19-inch rack mount
19-inch rack mount
The rack-mount design allows the switch to be easily installed on an industry-standard-sized rack, which saves you a tremendous amount of space. The ability to keep it inside a cabinet protects the switch from pests, dust, climates, accidents and much more.
Auto-MDI/MDIX Port
The auto MDI/MDIX feature makes it possible to automatically correct errors in cable selection，making the distinction between a "straight through" cable
Provides up to 16 auto-sensing 10/100/1000Mbps Gigabit Ethernet ports (10 times faster than standard Fast Ethernet ports) with a non-blocking switching architecture for maximum throughput at wire speed.
16 10/100/1000Mbps RJ45 ports
Provides up to 16 auto-sensing 10/100/1000Mbps Gigabit Ethernet ports (10 times faster than standard Fast Ethernet ports) with a non-blocking switching architecture for maximum throughput at wire speed.
Easy Use & Installation
The auto features of this desktop switch make installation plug and play and hassle-free. It can detect and configure devices automatically, without requiring the user to physically configure the devices.
Energy Efficient Design
This AR-GS216 features the latest innovative energy-efficient technologies, which can greatly expand your network capacity with much less power. It can automatically adjust your power consumption according to the link status and cable length to limit the carbon footprint of your network. Most affordable connectivity to your network.
General
Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Protocol
- CSMA/CD
Data Rate
- Ethernet: 10Mbps (Half Duplex)/20Mbps (Full Duplex)
- Fast Ethernet: 100Mbps (Half Duplex)/200Mbps (Full Duplex)
- Gigabit Ethernet: 2000Mbps (Full Duplex)
Topology
- Star
Performance
Transmission Method
- Store-and-Forward
MAC Address Table
- 8K entries per device
Forwarding Rate
- Full wire speed
MAC Address Learning
- Self-learning, auto-aging
Hardware
Interfaces
- Sixteen 10/100/1000Base-TX Ports
AC Power Supply
- Rated voltage: 100-240 V, 50/60 Hz
- Maximum voltage: 90-264 V, 50/60 Hz
Fan
- A Built-in 40 mm x 40 mm x 20mm Fan
Power Supply
- External Power Adapter
(Input: AC 100-240V, 50/60Hz, Output: DC 5V 0.5A)
Dimensions (W x D x H)
- 19 Inch, 1U rack-mount size
Weight
- 2.1kg
Environment
Operating Temperature
- 0°C~40°C (32°F~104°F)
Storage Temperature
- -40°C~70°C (-40°F~158°F)
Relative Humidity
- 10%~90%, non-condensing
Storage Humidity
- 5%~90%, non-condensing
Certifications
- CE, RoHS
