EnGenius ECS5512F Cloud 12-Port 10 Gigabit SFP+ Half-Rack Aggregate Fiber Switch
เพิ่มเมื่อ: 2025-02-08 12:31:58.0
แก้ไขล่าสุด: 2025-02-08 12:32:28.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comMulti-Gigabit Switch EnGenius ECS5512F Cloud 12-Port 10 Gigabit SFP+ Half-Rack Aggregate Fiber Switch
EnGenius ECS5512F
Multi-Gigabit Switch EnGenius ECS5512F Cloud 12-Port 10 Gigabit SFP+ Half-Rack Aggregate Fiber Switch
EnGenius Cloud Managed Layer 2+ Aggregate Switch, ECS5512F is a reliable and easy-to-manage 12-Port 10G SFP+ uplink ports switch that provides high-speed connectivity for your network devices. Its Zero-touch provisioning and centralized cloud management make it easy to set up and manage your network from anywhere, anytime. With its Voice-VLAN feature and robust security, you can ensure quality voice and video traffic while protecting against malicious attacks.
- 8x 10G ports to support ultra-high bandwidth applications
- 4x Dual-Speed 10G SFP+ (fiber) uplink ports to high-speed NAS and servers for a high-performance network
- Zero touch provisioning, centralized cloud management and visualized monitoring
- Hybrid cloud switch supports flexible management options such as EnGenius Cloud or standalone
- Robust security that supports Port based / MAC based ACL Storm control, DHCP Snooping, DOS Attack Prevention, 802.1X & RADIUS Authentication and more
- Optimized for quality voice and video traffic with Voice-VLAN feature
Technical Specifications
Port Standards
802.3u 100Base-TX Ethernet
802.3ab 1000Base-T Ethernet
802.3bz 2.5G/5GBase-T Ethernet
802.3x Full-Duplex Flow Control
Network Ports
12x SFP+ Ports
Switching Capacity
240Gbps
SDRAM
512 MB
Flash Memory
128 MB
Power Source
100 ~ 240VAC, 50-60Hz
L2 Features
Network Management
EnGenius Cloud
Local Web GUI
MAC Address Table
32K
Jumbo frame size
10K
Multicast Group
Max 256 groups
MLD Snooping
MLD Snooping: v1
QoS-number of Priority Queues Supported/
Queue 8
QoS Trust Mode
Cos/802.1p
DSCP
CoS/802.1p-DSCP
Scheduling Mechanism
Strict / WRR/ Strict + WRR
Bandwidth Control
Port-based bandwidth control (Ingress/Egress)
Port Security
Max. 256 Entries
Access Control List (ACL)
MAC Based ACL
IPv4/IPv6 Based ACL
ACL Binding
Time base ACL
Web Graphical User Interface (GUI)
HTTP IPv4 / IPv6
HTTPS IPv4 / IPv6
SNMP
SNMP v1/v2c/v3 Support
RMON
RMON 1,2,3,9
System Time
Time Setting/Daylight saving
Common L2 Features
802.1D Spanning Tree
802.1w Rapid Spanning Tree
802.1S Rapid Spanning Tree
Loopback Detection
Multicast Filitering
IGMP Snooping
802.1Q VLAN tagging
802.3x flow control
802.3ad Link Aggregation
IPv4 DHCP Relay
IPv4 DHCP Snooping
IPv4 DHCP Snooping Source MAC Address Check-up
ARP Packet Validation (additional validation checks)
Voice VLAN
Port-based VLAN
CoS Mapping
802. 1X Radius Authentication Protocol
IPv4 Settings/ IPv6 Settings
Command Line Interface (CLI)
SSH Server
Telnet Server
TFTP Client
Configuration Upgrade/ Backup
Simple Network Time Protocol (SNTP)
SYSLOG
L3 Features
Multiple IP Interface
20 IPv6 address
ARP Table
Max. 192 ARP entries
IPv4 Static Route
Max. 63 entries
IPv6 Static Route
Max. 21 entries
ECS2512F Device
Weight: 1.39 kg
Width: 210 mm
Length: 230 mm
Height: 44 mm
Dimensions & Weight
Package Contents
1x Cloud Managed Gigabit Switch
1x Product Card
1x Power Cord
1x RJ45 Console Cable
1x Rack Mount Kit
