TP-LINK Deco M4(1-Pack)
Deco M4(1-Pack) AC1200 Whole-Home Mesh Wi-Fi System, Qualcomm CPU, 867Mbps at 5GHz+300Mbps at 2.4GHz , 2 Gigabit Ports, 2 antennas, MU-MIMO, Beamforming
- Deco uses a system of units to achieve seamless whole-home Wi-Fi coverage — eliminate weak
signal areas once and for all!
- With advanced Deco Mesh Technology, units work together to form a unified network with a single
network name. Devices automatically switch between Decos as you move through your home
for the fastest possible speeds.
- A Deco M4 two-pack delivers Wi-Fi to an area of up to 2,800 square feet (EU version)†. And if that’s not
enough, simply add more Decos to the network anytime to increase coverage.
- Deco M4 provides fast and stable connections with speeds of up to 1167 Mbps† and works with major
internet service provider (ISP) and modem.
- Deco can handle traffic from even the busiest of networks, providing lag-free connections
for up to 100 devices†.
- Parental Controls limits online time and block inappropriate websites according to unique profiles created
for each family member.
- Setup is easier than ever with the Deco app there to walk you through every step.
POWER
AC adapter input
- 100-240V ~ 50/60Hz 0.4A
AC adapter output
- 12V ⎓ 1.2A
HARDWARE FEATURES
Processor
- Qualcomm CPU
Interface
- 2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit
Button
- 1 Reset button on the underside
External Power Supply
- 12 V/1.2 A
Dimensions
- Φ3.6 in. x 7.5 in. (Φ90.7 mm x 190 mm)
Antenna Type
- 2 internal dual-band antennas per Deco unit
WIRELESS FEATURES
Wireless Standards
- IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz
Frequency
- 2.4 GHz and 5 GHz
Signal Rate
- 300 Mbps on 2.4 GHz
- 867 Mbps on 5 GHz
Transmit Power
- FCC: <30 dBm
- CE: <20 dBm (2.4 GHz)
- <23 dBm (5 GHz)
Wireless Security
WPA-PSK/WPA2-PSK
Advanced Functions
● Router/ Access Point Mode
● Optional Ethernet Backhaul
● Guest network
● TP-Link Mesh Technology:
MU-MIMO
Auto Path Selection
Self-Healing
AP Steering
Band Steering
Beamforming
SOFTWARE FEATURES
Quality of Service
- WMM
IPv6
- Support
WAN Type
- Dynamic IP/Static IP/PPPoE/L2TP/PPTP
Management
- Local Management, Remote Management
- 1 Deco unit
- 1 RJ45 Ethernet Cable
- 1 power adapter
DHCP
- Server, Client
Port Forwarding
- Support
Access Control
- Blacklist
Firewall Security
- SPI Firewall
Protocols
- Supports IPv4 and IPv6
Advanced Features
- Parental Controls
- Quality of Service
Advanced Functions
- Monthly Reports
- Auto FW Update
- Expand Wi-Fi by adding more Deco units
Guest Network
- 2.4 GHz guest network x 1
- 5 GHz guest network x 1
Beamforming
- Support
APP
- Easy setup via Deco App
OTHERS
Certification
- CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS
Package Contents
- ● Deco M4 (3-pack):
3 Deco units
1 RJ45 Ethernet Cable
3 power adapters
1 quick installation guide
● Deco M4 (2-pack):
2 Deco units
1 RJ45 Ethernet Cable
2 power adapters
1 quick installation guide
● Deco M4 (1-pack):
1 quick installation guide
Smartphone/Tablet Requirements
- iOS 9.0 or later
- Android 4.3 or later
Environment
- Operating Temperature: 0℃~40℃ (32℉~104℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
