TP-LINK RP108GE Omada 8-Port Gigabit Reverse PoE Switch
เพิ่มเมื่อ: 2024-10-19 12:19:31.0
แก้ไขล่าสุด: 2024-10-19 12:20:13.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comPoE Switch TP-LINK RP108GE Omada 8-Port Gigabit, 7× Gigabit Passive PoE In Ports, 1× Gigabit Passive PoE Out Port
TP-LINK RP108GE
PoE Switch TP-LINK RP108GE Omada 8-Port Gigabit, 7× Gigabit Passive PoE In Ports, 1× Gigabit Passive PoE Out Port
- 7 PoE input and 1 PoE output 10/100/1000 Mbps RJ45 Ports
- 1 DC output port that supports both 5V and 12 V voltage switching
- Durable metal casing of superior quality and professional appearance
- Intelligent management via a web user interface and downloadable utility
- Green technology reduces power consumption
Interface
• 7× Passive PoE-in RJ45 Ports
• 10/100/1000Mbps Auto-Negotiation
• Voltage: 24/48 V (mixture is not supported)
• Power pin of Ethernet cable: 4/5+ 7/8-
• 1× Passive PoE-out RJ45 Port:
• 10/100/1000Mbps Auto-Negotiation
• Voltage: depending on the input voltage of PoE-in ports
• Power pin of Ethernet cable: 4/5+ 7/8-
• 1× DC Output Port
• Voltage: 5/12 V
Network Media
• 10Base-T:
UTP category 3, 4, 5 cable (maximum 100 m)
EIA/TIA-568 100 Ω STP (maximum 100 m)
• 100Base-TX:
UTP category 5, 5e cable (maximum 100 m)
EIA/TIA-568 100 Ω STP (maximum 100 m)
• 1000Base-T:
UTP category 5e cable (maximum 100 m)
EIA/TIA-568 100 Ω STP (maximum 100 m)
Packet Forwarding Rate : 11.9 Mbps
Mac Address Table : 4 K
Jumbo Frame : 16 KB
Switching Capacity : 16 Gbps
IEEE Standards :
IEEE802.3ab, IEEE802.3i, IEEE802.3p
IEEE802.3q, IEEE802.3x, IEEE802.3u
Data Rates :
• Ethernet: 10 Mbps (Half Duplex), 20 Mbps (Full Duplex)
• Fast Ethernet: 100 Mbps (Half Duplex), 200 Mbps (Full Duplex)
• Gigabit Ethernet: 2000 Mbps (Full Duplex)
LED Indicator : Power, Link/Act LED
Dimensions ( W x D x H ) : 6.2 × 3.9 × 1.0 in (158 × 99.1 × 25 mm)
Max Power Consumption :
• 3.98 W (with no PD connected)
• 18.01 W (24 V with PD connected)
• 32.74 W (48 V with PD connected)
Max Heat Dissipation :
• 13.57 BTU/h (with no PD connected)
• 61.41 BTU/h (24 V with PD connected)
• 111.64 BTU/h (48 V with PD connected)
Package Contents
• RP108GE
• Power Cord
• Installation Guide
• Rubber Feet
System Requirements : Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.
