| D-LINK DGS-3130-54S 54-Port Lite Layer 3 Stackable Managed Gigabit Fiber Switch
D-LINK DGS-3130-54S 54-Port Lite Layer 3 Stackable Managed Gigabit Fiber Switch
เพิ่มเมื่อ: 2023-08-26 16:42:36.0
แก้ไขล่าสุด: 2023-10-09 10:49:52.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comDGS-3130-54S 54-Port Lite Layer 3 Stackable Managed Gigabit Fiber Switch
D-LINK DGS-3130-54S
DGS-3130-54S 54-Port Lite Layer 3 Stackable Managed Gigabit Fiber Switch, 48-port SFP, 2-port 10GBase-T, 4-port 10G SFP+
- 48 x SFP ports
- 2 x 10GBASE-T and 4 x 10G SFP+ ports provide all the uplink capacity your network needs
- Premium L2 and L3 features effortlessly improve network efficiency and reduce unnecessary data transfer
- High redundancy features to provide professional-grade reliability and a longer product life:
— Dual power inputs
— Ethernet Ring Protection Switching with <50ms recovery time
— 6 kV surge protection protects the device and those connected from unexpected surges
— 802.1d/w/s Spanning Tree Protocol avoids potentially network crippling loops
- RIP/RIPng and OSFPv2/v3 dynamically maps out your network, aiding data to get to its destination via the fastest route possible.
- Expand capacity in a flash with physical stacking up to 9 units
- 80 Gbps per device physical stacking bandwidth
- The Smart Fan self-adjusts accordingly to maintain optimal operating temperatures
Specifications
- IPv6 Neighbor Discovery (ND) Yes
- ND Entries 1,024
- UDP Helper Yes
- VRRP Yes
- Routing Table Entry 1,024
- L3 Forwarding Table Entry 4,096
- Equal-Cost Multi-Path Route (ECMP) Yes
- Weighted-Cost Multi-Path Route (WCMP) Yes
- Default Route Yes
- Static Route Yes
- Policy-based Route (PBR) Yes
- Null Route Yes
- Route Preference Setting Yes
- Route Redistribution Yes
- RIPv1 Yes
- RIPv2 Yes
- RIPng Yes
- Class of Service (CoS) Yes
- Two Rate Three Color Marker (trTCM) Yes
- Single Rate Three Color Marker (srTCM) Yes
- Number of Queue 8
- Remark 802.1p priority Yes
- Remark ToS/DSCP Yes
- Rate Limiting Yes
- Time based QoS Yes
- Queue Handling Yes
- Strict Priority Queue (SPQ) Yes
- Weighted Round Robin (WRR) Yes
- Weighted Deficit Round Robin (WDRR) Yes
- SPQ + WRR Yes
- Weighted Random Early Detection (WRED) Yes
- Simple Random Early Detection (SRED) Yes
- Port-based Bandwidth Control Yes
- Flow-based bandwidth Control Yes
- Queue-based Bandwidth Control Yes
- Max Access Control List (ACL) Entries Yes
- MAC Access List Yes
- IP Access List Yes
- IPv6 Access List Yes
- Time based ACL Yes
- CPU Interface Filtering Yes
- SSH Yes
- SSL Yes
- Port Security Yes
- Broadcast/Multicast/Unicast Storm Control Yes
- Traffic Segmentation Yes
- IP-MAC-Port Binding (IMPB) Yes
- IP Source Guard Yes
- DHCP Snooping Yes
- IPv6 Snooping Yes
- Dynamic ARP Inspection (DAI) Yes
- DHCPv6 Guard Yes
- IPv6 Route Advertisement (RA) Guard Yes
- IPv6 ND Inspection Yes
- D-Link Safeguard Engine Yes
- L3 Control Packet Filtering Yes
- NetBIOS/NetBEUI filtering Yes
- DHCP Server Screening Yes
- DHCP Client Filtering Yes
- ARP Spoofing Prevention Yes
- BPDU Attack Protection Yes
- DoS Attack Prevention Yes
- 802.1X Yes
- Port based 802.1X Authentication Yes
- Host based 802.1X Authentication Yes
- Identity Driven 802.1X Policy Assignment Yes
- Web-based Access Control (WAC) Yes
- Port based WAC Authentication Yes
- Host based WAC Authentication Yes
- Identity Driven WAC Policy Assignment Yes
- MAC-based Access Control (MAC) Yes
- Port based MAC Authentication Yes
- Host based MAC Authentication Yes
- Identity Driven MAC Policy Assignment Yes
- Compound Authentication Yes
- Guest VLAN Yes
- Microsoft® NAP Support Yes
- Authentication for Management Access Yes
- Privilege Level for Management Access Yes
- RADIUS Yes
- RADIUS Accounting Yes
- TACACS+ Yes
- Authentication Database Failover Yes
- Trusted Host Yes
- Cable Diagnostics Yes
- 802.3ah Ethernet Link OAM Yes
- D-link Unidirectional Link Detection (DULD) Yes
- Dying Gasp Yes
- 802.1ag Connectivity Fault Management (CFM) Yes
- Y.1731 OAM Yes
- Optical Transceiver Digital Diagnostic Monitoring (DDM) Yes
- Network Time Protocol (NTP) Yes
- Simple Network Time Protocol (SNTP) Yes
- Web-based GUI Yes
- Command Line Interface (CLI) Yes
- Telnet Client Yes
- Telnet Server Yes
- SNMP Yes
- TFTP Client Yes
- SNMP Trap Yes
- ZModem Yes
- Secured FTP (SFTP) Server Yes
- System Log Yes
- Command Logging Yes
- SMTP Yes
- RMONv2 Yes
- RMONv1 Yes
- LLDP Yes
- D-Link Discover Protocol (DDP) Yes
- LLDP-MED Yes
- DHCP/BootP Client Yes
- DHCP Auto-configuration Yes
- DHCP relay Yes
- DHCP Server Yes
- PPPoE Circuit-ID Tag Insertion Yes
- Flash file system Yes
- Dual Images Yes
- Multiple Images Yes
- Dual Configurations Yes
- Multiple Configurations Yes
- Editable Login Banner Yes
- Editable System Prompt Yes
- DNS Client Yes
- Debug Command Yes
- Password Recovery Yes
- Password Encryption Yes
- MTU Setting Yes
- Traceroute Yes
- Ping Yes
- Microsoft® Network Load Balancing (NLB) Yes
- sFlow Yes
