TENDA O9 5GHz 11ac Wireless Access Point Gigabit Outdoor CPE 23dBi

 เพิ่มเมื่อ: 2021-02-04 10:59:02.0
 แก้ไขล่าสุด: 2021-02-04 11:01:47.0
 เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
 อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
O9 5GHz 11ac Wireless Access Point Gigabit Outdoor CPE 23dBi with Passive PoE, AP/Station/WISP/P2MP/WDS Repeater/Router (สินค้ารับประกัน 5 ปี)
3490.00 บาท

 TENDA O9

O9 5GHz 11ac 23dBi Gigabit Wireless Access Point Outdoor CPE with Passive PoE, AP/Station/WISP/P2MP/WDS Repeater/Router

  O9 5GHz 11ac 23dBi gigabit outdoor CPE is designed to PtP and PtMP solutions for privated ISP wireless connectivity, CCTV surveillance and data transmission. It features with 23dBi directional dual polarization antenna to provide an efficient way to pick up and maintain a stable long-distance connectivity up to 25km. Adopt of auto-bridging technology, two CPE can connect to each other automatically to make it easy to setup.

Frequency Range5GHz

Compliant StandardsIEEE 802.11a/n/ac

Private TDMA ProtocolTD-MAX

Maximum Wireless Rate867Mbps

Interface1*10/100/1000Mbps Ethernet Port

Antenna gain23dBi

Antenna BeamwidthHorizontal: 10° Vertical: 10°

Reset Button1

Power Consumption7.5W

Waterproof LevelIP65

Dimension391.5*280*223mm

DeploymentPole Mount

Application ScenariosPtP and PtMP wireless connection for Privated ISP access or CCTV Surveillance

LEDPoE/LAN,LED1,LED2,LED3

Power Method24V0.5A Passive PoE

Lightning Protection6000V

Passive PoEPassive power over ethenet via PoE/LAN (+4,5pins

-7,8pins )

Voltage range: 21-25V DC

Reception Sensitivity11a 6Mbps -96dBm±1.5dBm

11n MCS7 HT20 -72dBm±1.5dBm

11ac MCS9 HT80 -65dBm±1.5dBm

Operating ModeAP/Station/WISP/P2MP/WDS Repeater/Router

Enable/Disable Wireless RadioSupport

SSID HiddenSupport

Wireless Client isolationSupport

SSID IsolationSupport

Channel Bandwidth20/40/80MHz

Channel ShiftSupport

Wireless Access ControlSupport

Weak Signal Client LimitationSupport

Transmit PowerAdjustable power by 1dBm

WMM CapableSupport

APSD CapableSupport

Wireless Security64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2

Package Content

1*5GHz 11ac 23dBi Gigabit Outdoor CPE O9
1*PoE Power Adapter
1*Quick Installation Guide
