TP-LINK TL-SG1008P 8-Port Gigabit PoE Switch, 8 Gigabit RJ45 Port including 4 PoE Port, steel case

 เพิ่มเมื่อ: 2013-11-05 18:02:03.0
 แก้ไขล่าสุด: 2023-11-23 16:29:44.0
 เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
 อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
TL-SG1008P 8-Port Gigabit Desktop Unmanaged PoE Switch with 4-Port PoE (สินค้ารับประกัน ตลอดอายุการใช้งาน)
2200.00 บาท

TP-LINK TL-SG1008P

TL-SG1008P 8-Port Gigabit Desktop Unmanaged PoE Switch with 4-Port PoE

- 8 10/100/1000Mbps RJ45 ports

With four PoE ports, transfers data and power on one single cable

- Supports PoE power up to 15.4W for each PoE port

- Supports PoE power up to 53W for all PoE ports

- Supports PoE IEEE 802.3af compliant PDs

- Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode

- 8K entry MAC address table of the TL-SG1008P with auto-learning and auto-aging

- LED indicators for monitoring power, link, activity and speed

- External power adapter supply



Specifications



HARDWARE FEATURES
Interface 8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
PoE Ports (RJ45) Standard: 802.3 af compliant
PoE Ports: Port1- Port4
Power Supply: 53W
Backbound Bandwidth 16Gbps
Mac Address Table 8K
External Power Supply External Power Adapter(Output: 48VDC / 1.25A)
Dimensions (W X D X H) 6.7*3.9*1.1 in. (171*98*27 mm)
Fan Quantity Fanless
SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions Compatible With IEEE 802.3af Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode
OTHERS
Certification FCC, CE, RoHS
Package Contents TL-SG1008P, Power Adapter, User Guide
Consumption 5.8 watts (max. no PD connected)
58.8 watts (max. with 53w PD connected)
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
